Ballistor

The Ballistor separates out usable fractions from waste and potential recyclables. By combining ballistic separation with screening, in just one pass-through the material stream is separated to the criteria 3/2-dimensional, rolling-cubic-rigid/ flat-soft-narrow, and particle size. This means that high-caloric fractions can be separated out of commercial or household waste and further processed into RDF in one operation.

Technical Specifications

Separation System:
ballistic separator with vibrating plate
Motor Type:
electric
Power:
55–90 kW
Throughput Capacity: up to 200 m³/h
Throughput Capacity: up to 200 m³/h
Number of Fractions:
3 (flat, rolling, fine)
Angle Adjustment:
0–20°
Design:
stationary, modular
Additional Equipment:
airflow control system, dust collection solutions

The Ballistor’s long-life components, readily replaceable wear elements, and excellent maintenance access keep operating costs low. With four sizes and many options, the Ballistor separator can be configured to suit the application.
