Drum screens stationary

With stationary drum screens, a corresponding screening machine is available for every system size. Directly driven heavy-duty supporting wheels (1845/2055: DRUMGRIP-drive) provide quiet drum operation and top efficiency with reduced energy consumption and noise emissions. Variable configuration of sub-structure, servicing accessibility, enclosure and drive simplify adaptation to on-site conditions.

Technical Specifications

Drum Length:
5.5–7.2 m (depending on model)
Drum Diameter:
up to 2.2 m
Engine Power:
80–120 kW
Motor Type:
electric
Throughput Capacity:
up to 180 m³/h
Number of Fractions:
2–3 separated fractions
Design:
stationary, designed for continuous operation
Screening System:
quick-change screens, adaptable for different materials
